Heavy alloy is the generic name for tungsten-based, high-density alloy and contains nickel, copper and iron as additives for homogeneous sintering. The tungsten alloy THA Standard is classified according to composition, or tungsten content,and the sorts of additive. The alloy is widely used as the key material for nuclear devices because it excels in mechanical properties, radiation-shielding properties and thermal resistance. Unlike pure tungsten material, heavy alloy is easily machined and precision finished by turning, milling, boring, threading and grinding.
Material property of THA
properties |
THA-17 |
THA-17N |
THA-175 |
THA-175N |
THA-175W |
Composition(%) |
90WNIFECU |
90WNICU |
92.5WFeNiCu |
92.5 WNiCu |
95WMoNiFe |
Density(gm/cc) |
17.0 |
17.0 |
17.5 |
17.5 |
17.5 |
Magnetic Permeability (Mu) |
>7.0 |
1.03 |
7.0 |
1.03 |
3.0 |
Modulus of Elasticity (GPa) |
276 |
276 |
310 |
310 |
310 |
Tensile Strength(MPa) |
827 |
758 |
827 |
758 |
862 |
Yield Strength(MPa) |
586 |
620 |
620 |
586 |
620 |
Elongation(%) |
10 |
6 |
12 |
6 |
8 |
Hardness(HRC) |
26 |
25 |
27 |
26 |
30 |
properties |
THA-18 |
THA-18N |
THA-185 |
|
|
Composition(%) |
90WNIFECU |
90WNICU |
92.5WFeNiCu |
|
|
Density(gm/cc) |
18.0 |
18.0 |
18.5 |
|
|
Magnetic Permeability (Mu) |
5.0 |
1.03 |
3.0 |
|
|
Modulus of Elasticity (GPa) |
345 |
345 |
365 |
|
|
Tensile Strength(MPa) |
827 |
758 |
793 |
|
|
Yield Strength(MPa) |
620 |
586 |
586 |
|
|
Elongation(%) |
8 |
5 |
6 |
|
|
Hardness(HRC) |
28 |
27 |
30 |
|
|
Chinatungsten specializes in manufacturing and offering tungsten alloy products based on tungsten alloy grades, any enquiry will be warmly welcome by email to sales@chinatungsten.com sales@xiamentungsten.com or telephone to 0086 592 5129696.
